UB-MLQ260J Full Automatic Face Angle Grinding Machine (Robot Arm)
Fully automatic front-angle grinding equipment for carbide circular saw blades, with a robot arm for automatic loading and unloading.
Blade Range
Blade diameter Ø100—Ø260 mm; arbor size Ø12—Ø50 mm (special specifications can be customized); tooth pitch 5—65 mm.
Arbor Size (mm)Ø12—Ø50
Max Tooth Pitch (mm)65
Grinding Speed (Teeth/min)20
Back Angle (°)0—+30
Highlights
- 半封闭环保设计；机械臂自动夹持锯片，一人可操作 10—15 台；PLC 与伺服控制支持微量进给；支持多种齿形程序与特殊齿形磨削量设置；砂轮自动补偿。
Where It Fits
Step 7 of 10 in the circular saw blade production line.
Previous: Welding Strength Testers
Next: Cleaning Machines
Full Specifications
| Specification | Value |
|---|---|
| Arbor Size (mm) | Ø12—Ø50 mm |
| Max Tooth Pitch (mm) | 65 mm |
| Grinding Speed (Teeth/min) | 20 Teeth/min |
| Back Angle (°) | 0—+30 ° |
| Grinding Length (mm) | 0—25 mm |
| Front Bevel Angle · Front Angle (°) | ±45 ° |
| Diamond Wheel · Front Angle (mm) | Ø125×20×5 mm |
| Diamond Wheel Grit · Front Angle | 220#; 280# |
| Grinding Precision (mm) | ≤0.03 mm |
Compare in This Group
| Specification | UB-MLQ260JFull Automatic Face Angle Grinding Machine (Robot Arm) | UB-MLQ300FFull Automatic Face Angle Grinding Machine (Robot Arm) | UB-MLQ300JFull Automatic Face Angle Grinding Machine (Robot Arm) | UB-MLQ650CAutomatic Move-Working Face Angle Grinding Machine | UB-MLQ650JAutomatic Move-Working Face Angle Grinding Machine |
|---|---|---|---|---|---|
| Arbor Size (mm) | Ø12—Ø50 | Ø12—Ø50 | Ø12—Ø50 | Ø12—Ø50 | Ø12—Ø50 |
| Max Tooth Pitch (mm) | 65 | 65 | 5—65 | 5—65 | 5—65 |
| Grinding Speed (Teeth/min) | 20 | 20 | 20 | 20 | 20 |
| Front Bevel Angle · Front Angle (°) | ±45 ° | -15—15 ° | -15—15 ° | ±45 ° | ±45 ° |
