Sand Blasting Machines
UB-PX400J Full Automatic Sand Blasting Machine (Robot Arm)
Automatic sand blasting equipment for surface treatment of carbide circular saw blades, with a robot arm for automatic loading and unloading.
Blade Range
Blade diameter Ø100—Ø400 mm; arbor size Ø10—Ø50 mm; special specifications can be customized.
Arbor Size · Custom Specifications (mm)Ø10—Ø50
Compressed Air Pressure (MPa)≤0.9
Grit Sizes · Recommended Use36# / 46#
Voltage380V (Three-Phase Four-Wire)
Highlights
- 封闭式环保防护设计；机械臂自动上下料，一人可管理 5—6 台设备；来源声称单班产能约 2500 片；三喷枪同步移动机构便于换型与调节；集中除尘，砂料可循环利用；操作简便、无粉尘。
Where It Fits
Step 5 of 10 in the circular saw blade production line.
Previous: Brazing Machines
Next: Welding Strength Testers
Full Specifications
| Specification | Value |
|---|---|
| Arbor Size · Custom Specifications (mm) | Ø10—Ø50 mm* |
| Compressed Air Pressure (MPa) | ≤0.9 MPa |
| Grit Sizes · Recommended Use | 36# / 46# |
| Voltage | 380V (Three-Phase Four-Wire) |
| Main Unit Dimensions (mm) | 1830×2580×2200 mm |
| Dust Collector Dimensions (mm) | 2000×1900×2010 mm |
| Other Configuration | Air Tank and Air Compressor |
* Custom specification available on request.
Compare in This Group
| Specification | UB-PX305JFull Automatic Sand Blasting Machine (Robot Arm) | UB-PX400JFull Automatic Sand Blasting Machine (Robot Arm) |
|---|---|---|
| Arbor Size · Custom Specifications (mm) | Ø10—Ø50 | Ø10—Ø50 |
| Compressed Air Pressure (MPa) | ≤0.9 | ≤0.9 |
| Grit Sizes · Recommended Use | 36# / 46# | 36# / 46# |
| Voltage | 380V (Three-Phase Four-Wire) | 380V (Three-Phase Four-Wire) |
