Machine Application:
- Pliers
- Ratchet spanner
- Other milling or drilling operations
Machine Features:
- One clamping for three operations
There are three axial outputs on each headstock, so it can mount three tools. This will save tool changing time because of once work piece clamping for three operations.
- Compound machine with two headstocks and work table
There are two head stocks and two work tables, so these equal two CNC machines integrated. One operator can operate two work positions, so the floor covering will be less.
- Dual channel controller
CNC system adopts the dual channel designing and parameterization programming, which is convenient to operate and reliable.
- Standard CNC machine designing
The machine structure and manufacturing adopt the CNC machining center designing and manufacturing standards which is high precise and reliable.
- Chip conveyor
The machine tool is shielded completely and equipped with chip conveyor system which can achieve the organized and clean working environment.
- Full machine enclosure
The machine is enclosed fully, so the working environment is clean and organized.
Machine Specifications:
| Parameters | Unit | 6GX |
| Worktable | mm | 400×400 |
| Max.loading | kg | 400 |
| T slot | mm | 3×18×115 |
| Max.X axis travel | mm | 300 |
| Max.Y axis travel | mm | 250 |
| Max.Z axis travel | mm | 400 |
| Spindle nose to worktable | mm | 140-540 |
| Max. speed | r/min | 1440 |
| Spindle motor | kw | 4KW |
| Spindle tapper | Morse 4 | |
| Guide rail | X/Y: linear rail ; Z:boxway | |
| Positioning precision | mm | 0.01 |
| Repeated positioning precision | mm | 0.005 |
| Total power | kw | 3 phase 380V 30KW |
| Dimension | mm | 3200×3500×3000 |
| Weight | kg | 9000 |
